ABL 1W1121 Wallbox 11kW 3 fases com tomada Type-2

Charging an electric vehicle at home with a standard outlet is slow and often impractical. The ABL 1W1121 Wallbox solves this by delivering 11 kW of three-phase AC power, cutting charging times significantly compared to a domestic socket.

Who is it for

This wallbox is for EV owners who want a reliable, fixed charging station at home or in a semi-public setting. It suits drivers of vehicles that support three-phase AC charging up to 11 kW.

Main features

• 11 kW charging power via 3-phase 400 V AC input
• Type 2 socket (IEC 62196-2) for standard charging cables
• Integrated 6 mA DC fault current detection for safety
• Wall-mounted design with UV-resistant polycarbonate housing
• LED status display for clear operation feedback

Specifications

• Charging power: 11 kW
• Charging current: 16 A
• Phases: 3-phase
• Input voltage: 400 V AC
• Frequency: 50 Hz
• Output connector: Type 2 socket
• DC fault current detection: 6 mA integrated
• Protection class: IP54
• Impact resistance: IK08
• Mounting type: Wall-mounted
• Operating temperature: -30°C to +50°C
• Housing material: UV-resistant plastic (polycarbonate)
• Colour: Black/Grey (RAL 7016 / RAL 9005)
• Status indication: LED display
• Access control: None
• Communication interface: None
• Energy meter: Not integrated

Tips

Ensure your electrical installation can supply 400 V three-phase power and is protected by a suitable circuit breaker. The Type 2 socket allows you to use your own charging cable, which can be stored separately when not in use.
