AXING AX BVE 20-01 tomada de antena TV/rádio

The AXING AX BVE 20-01 is a high-quality TV/Radio antenna end socket designed for flush-mount installation in single-cable systems. It provides two separate outputs for TV and radio, ensuring optimal signal distribution with minimal loss. The metal chassis offers excellent shielding, making it ideal for cable TV (DVB-C), terrestrial antenna (DVB-T/T2), and FM radio applications.

Advantages

This end socket delivers reliable performance with low insertion loss and high isolation between TV and radio outputs. Its compact design fits standard flush-mount frames, and the metal housing provides robust protection against interference.

Suitable for

• Residential and commercial installations requiring separate TV and radio connections
• Single-cable systems in cable TV and terrestrial antenna networks
• Flush-mount setups with compatible frames and covers

Key specifications

• Product Type: TV/Radio Antenna End Socket
• Input Connector: IEC Female
• TV Output Connector: IEC Male
• Radio Output Connector: IEC Female
• Frequency Range (TV): 5 - 862 MHz
• Frequency Range (Radio): 87.5 - 108 MHz
• Insertion Loss: Approx. 1.5 dB (TV and Radio)
• Isolation (TV to Radio): >20 dB
• Return Loss: >10 dB
• Impedance: 75 Ohm
• Shielding Factor: >75 dB
• DC Pass: No
• Mounting Type: Flush-mount
• Housing Material: Metal chassis
• Number of Outputs: 2 (1x TV, 1x Radio)
• Standard: EN 50083-4

Recommendations

For best performance, use with high-quality coaxial cables and ensure proper grounding. Compatible with standard 55mm flush-mount boxes and frames.
