AXING BAB 4-16P - derivador de satélite de 4 vias, atenuação de derivação 16 dB, 5-2400 MHz, conectores F

In satellite TV distribution systems, the AXING BAB 4-16P is used by installers to split the signal from a main trunk line to four subscriber outlets while maintaining a strong through signal for downstream taps. This 4-way satellite tap features a tap loss of 16 dB on each output and a low through loss of 2.0 dB (5-1000 MHz) or 2.5 dB (1000-2400 MHz), ensuring efficient signal distribution across the 5-2400 MHz frequency range. The die-cast zinc housing provides durability and shielding effectiveness greater than 100 dB, making it suitable for indoor wall-mounted installations.

Key specifications

• Product type: Satellite Tap
• Number of outputs: 4
• Tap loss: 16 dB
• Through loss: 2.0 dB (5-1000 MHz), 2.5 dB (1000-2400 MHz)
• Frequency range: 5 - 2400 MHz
• Impedance: 75 Ohm
• Connector type: F-connector
• DC pass: Through line only
• Shielding effectiveness: >100 dB
• Isolation (tap-tap): >20 dB
• Return loss: >10 dB
• Housing material: Die-cast zinc
• Mounting type: Indoor, wall-mountable

Why choose it

The BAB 4-16P offers reliable signal distribution with minimal through loss, ensuring that downstream devices receive a strong signal. Its robust construction and high shielding make it a dependable choice for professional satellite installations.

Ideal use cases

• Distributing satellite TV signals to multiple rooms in residential buildings
• Connecting multiple receivers in a home or small commercial setup
• Extending a satellite distribution network with minimal signal degradation

Good to know

The tap outputs are DC-blocked, preventing interference from connected devices. The through line passes DC, allowing remote powering of amplifiers or LNBs.
