BOPLA TSH 35-2 suporte para calha DIN preto 20035000

In industrial control cabinets, electricians and panel builders rely on the BOPLA TSH 35-2 to mount terminal blocks, relays, and other components onto standard 35 mm DIN rails. This snap-on holder from the TSH series offers a secure and vibration-resistant connection, simplifying assembly and maintenance in automation and electrical installations.

Key specifications

• Mounting standard: EN 60715 TH35 (35 mm DIN rail)
• Material: Polyamide (PA)
• Colour: Black (RAL 9005)
• Flammability rating: UL 94 V-0
• Operating temperature range: -40 °C to +100 °C
• Dimensions: 40 mm depth × 10 mm width × 40 mm height
• RoHS compliant
• REACH compliant

Why choose it

The TSH 35-2 is made from high-quality polyamide, providing excellent mechanical strength and electrical insulation. Its UL 94 V-0 flammability rating ensures safety in demanding environments, while the wide operating temperature range makes it suitable for both cold and hot applications. The snap-on mounting mechanism allows tool-free installation, reducing assembly time.

Ideal use cases

• Securing terminal blocks and connectors in control panels
• Mounting relays, contactors, and small devices on DIN rails
• Organizing wiring in industrial automation systems
• Building custom DIN rail assemblies for prototyping or production

Good to know

The TSH 35-2 is part of BOPLA's TSH series of DIN rail holders, designed for compatibility with standard EN 60715 TH35 rails. Its compact dimensions (40 × 10 × 40 mm) allow dense packing on the rail, maximizing space utilization in enclosures.
