Borne de passagem Weidmüller, ligação por parafuso, 24 A, 800 V, 2 ligações, bege-escuro, montagem em calha DIN

The Weidmüller 1053660000 is a high-quality feed-through terminal block designed for reliable and secure electrical connections in industrial applications. With a screw connection system and robust construction, it ensures stable performance even in demanding environments. This terminal block is ideal for use in control cabinets, distribution boards, and automation systems.

Advantages

Easy and secure screw connection for solid and flexible wires; compact design saves space on DIN rail; high rated voltage and current capacity; wide operating temperature range; multiple international approvals ensure safety and compliance.

Suitable for

• Industrial control panels
• Power distribution systems
• Automation and process control
• Building infrastructure

Key specifications

• Type: Feed-Through Terminal Block
• Connection Method: Screw Connection
• Number of Connections: 2
• Number of Potentials: 1
• Mounting Type: DIN Rail (TS 35)
• Rated Voltage (IEC): 800 V
• Rated Current (IEC): 24 A
• Wire Size (Solid, IEC): 0.5 - 4 mm²
• Wire Size (Flexible, IEC): 0.5 - 2.5 mm²
• Wire Size (AWG, UL): 24 - 12 AWG
• Stripping Length: 10 mm
• Torque: 0.4 - 0.8 Nm
• Screw Size: M 2.5
• Insulation Material: Wemid (PA 66)
• Color: Dark Beige
• Operating Temperature: -50 °C to +120 °C
• Pollution Degree: 3
• Overvoltage Category: III
• Number of Levels: 1
• Approvals: cURus, CSA, EAC, KEMA, ATEX, IECEx

Recommendations

For optimal performance, use with appropriate DIN rail and ensure proper torque settings. Suitable for use in hazardous locations when installed per ATEX/IECEx guidelines.
