EFB PEL 42HE 800x1000 RAL7035 Parte 3 de 3 Porta frontal + Porta traseira + Painéis laterais

The EFB PEL-4280GR.G1SV-3 is a high-quality server rack cabinet component set, designed as Part 3 of 3 for a 42U enclosure. This set includes a single-leaf safety glass front door, a single-leaf perforated steel rear door (approx. 80% perforation), and two removable lockable side panels. Finished in RAL 7035 light grey, it is part of the EFB PEL series, known for robust construction and flexibility.

Advantages

This component set offers enhanced security and ventilation. The front safety glass door provides visibility while protecting equipment, and the perforated rear door ensures efficient airflow. Side panels are lockable for added security and can be removed for easy access. The set is fully compatible with the corresponding frame and roof components (sold separately) to complete a 42U 800x1000mm rack cabinet.

Suitable for

• Data centers and server rooms requiring a 42U 19-inch rack enclosure
• IT professionals assembling a complete EFB PEL series cabinet
• Applications needing high ventilation with perforated rear door
• Secure environments where lockable side panels are essential

Key specifications

• Rack Units: 42U
• External Width: 800 mm
• External Depth: 1000 mm
• External Height: 2055 mm
• Colour: RAL 7035 Light Grey
• Front Door: Single-leaf safety glass door
• Rear Door: Single-leaf perforated steel door (approx. 80% perforation)
• Side Panels: Removable and lockable
• Material: Powder-coated steel sheet
• Static Load Capacity: 800 kg
• Mounting Profile: 19-inch, depth-adjustable
• Cable Entry: Top and bottom with brush strips
• Ventilation: Passive ventilation, prepared for active fan units
• Locking System: Swivel lever handle with profile half cylinder (front/rear), key lock (side panels)
• Base: Levelling feet and castors included
• Protection Rating: IP20
• Assembly: Fully assembled
• Grounding: Integrated grounding kit

Recommendations

This product is Part 3 of 3. To complete the full 42U rack cabinet, you will need Part 1 (frame and roof) and Part 2 (rear door and side panels) or the full cabinet set. Verify compatibility with your existing EFB PEL components.
