EXSYS EX-3682 SATA3 para mSATA com moldura de montagem de 2,5 polegadas (9,5 mm)

Modern computers often lack legacy serial ports, yet many industrial devices, POS systems, and laboratory instruments still rely on RS-232. The EXSYS EX-3682 solves this by adding two RS-232 ports through a PCI Express x1 slot.

Who is it for

System integrators, IT administrators, and technicians who need to connect serial devices to a desktop or server with a PCIe slot. The low-profile bracket allows installation in slimline or small form factor cases.

Main features

• Two RS-232 serial ports via a single PCIe x1 slot
• ASIX AX99100 chipset for reliable performance
• Supports data rates up to 250 Kbps per port
• 128-byte FIFO buffer per port reduces CPU load
• Includes both standard and low-profile brackets
• Compatible with Windows and Linux

Specifications

• Host Interface: PCI Express x1
• Output Interface: RS-232
• Serial Ports Quantity: 2 ports
• Connector: 2x DB9 Male
• Chipset: ASIX AX99100
• Max Data Transfer Rate: 250 Kbps per port
• FIFO Buffer: 128-byte per port
• Flow Control: Hardware (RTS/CTS), Software (XON/XOFF)
• Data Bits: 5, 6, 7, 8
• Stop Bits: 1, 1.5, 2
• Parity: Even, Odd, None, Mark, Space
• ESD Protection: 15 KV (Human Body Model)
• Operating System Support: Windows XP/Vista/7/8/10/11, Linux Kernel 2.6.x and higher

Tips

Check the available PCIe slot length before purchase; the card is x1 but will fit in larger slots. For slimline cases, use the included low-profile bracket.
