EXSYS EX-6991 conversor DC/DC 24V 100W montagem em calha DIN

Industrial and embedded systems often face unstable or fluctuating DC input voltages, which can damage sensitive equipment or cause malfunctions. The EXSYS EX-6991 DC/DC converter solves this by providing a regulated 24V DC output from a wide 10-30V DC input, ensuring reliable power for your devices.

Who is it for

This converter is ideal for automation engineers, system integrators, and technicians who need to power 24V equipment in environments with 12V or 24V battery systems, such as vehicles, solar installations, or industrial control cabinets.

Main features

• Wide input voltage range: 10-30V DC, suitable for 12V and 24V systems.
• Stable 24V DC output with ±1% voltage tolerance and low ripple (<100mVp-p).
• High efficiency up to 88%, minimizing heat generation and energy loss.
• Robust metal housing with DIN rail mounting (TS-35/7.5 or TS-35/15) for easy installation.
• Comprehensive protection: short circuit, overload, over voltage, and reverse polarity.
• Wide operating temperature range: -20°C to +70°C (derating above +50°C).

Specifications

• Output power: 100 W
• Output current: 4.16 A
• Cooling: Free air convection
• MTBF: >200,000 hours (MIL-HDBK-217F)
• Connections: Screw terminals for input and output

Tips

Ensure proper ventilation around the converter, especially when operating near the upper temperature limit. For DIN rail mounting, use a compatible TS-35 rail and secure the unit firmly to avoid vibration issues.
