Fonte de alimentação/conversor Mean Well SPBW03G-12, 3 W, entrada 18–75 V, saída 12 V

Mean Well SPBW03G-12 is a compact DC-DC converter designed for PCB mounting in SIP through-hole format. The module accepts a wide input voltage range from 18 V to 75 V DC and delivers a regulated single 12 V DC output at up to 0.25 A (3 W). Intended for low-power embedded systems and industrial control circuits, this converter is RoHS-compliant and supplied in bulk packs suitable for production environments.

Advantages

The SPBW03G-12 provides a stable 12 V output across a broad input range, enabling reliable operation in applications with variable supply voltages. Its SIP through-hole package simplifies PCB assembly and mechanical mounting, while the small physical size conserves board space. With regulated output and protection features typical for Mean Well converters, it supports consistent performance for small electronics and sensor interfaces.

Suitable for

• Embedded systems and microcontroller boards requiring 12 V rail
• Industrial control circuits and measurement instruments
• Sensor interfaces and low-power data acquisition modules
• Small electronics and accessory power supplies on PCBs

Key specifications

• Type: DC-DC converter, PCB mount
• Package: SIP through-hole
• Input voltage range: 18–75 V DC
• Output voltage: 12 V DC (fixed)
• Output current: up to 0.25 A (3 W maximum)
• Efficiency: typical for low-power switching converters (refer to manufacturer datasheet)
• Compliance: RoHS

How to use

Install the converter on the PCB using the SIP through-hole pins and ensure correct polarity for input and output connections. Provide appropriate input filtering and decoupling on the board according to the application’s noise and transient requirements. Verify thermal conditions and ensure adequate spacing or airflow if the converter operates near its maximum power rating. Follow the manufacturer’s recommended application circuit and layout guidelines for reliable operation.

Recommendations

For stable long-term operation, avoid continuous operation at the maximum rated current and ensure the input voltage stays within the specified 18–75 V range. Use proper PCB layout and grounding practices and consult the Mean Well datasheet for detailed electrical characteristics, recommended capacitors, and thermal management instructions.
