Fonte de alimentação MEAN WELL MSP-1000-24 1000W 24V entrada 90-264V

The MEAN WELL MSP-1000-24 is an AC-DC enclosed medical single-output power supply providing 24 VDC at up to 42 A with a rated output power of 1000 W. It accepts a wide input range of 90–264 VAC, includes MOOP (Means of Patient Protection) compliance for medical applications, and offers remote ON/OFF control plus a DC OK signal for system monitoring. The unit has compact dimensions (105 mm × 218 mm × 63.5 mm) and meets RoHS requirements.

Advantages

The MSP-1000-24 delivers a high continuous output current of 42 A from a single 24 V rail, ensuring stable power for demanding loads. Wide input voltage support simplifies integration across different mains environments. Built-in remote ON/OFF and DC OK signal facilitate system control and monitoring. The enclosed design and MOOP compliance make it suitable for medical equipment where patient protection is required. Compact size allows installation in constrained spaces.

Suitable for

• Medical devices requiring MOOP-compliant 24 V power
• Industrial control systems and automation equipment
• Telecom and network equipment with high current demand
• Embedded systems and rack-mounted applications with limited space

Key specifications

• Model: MSP-1000-24
• Output: 24 VDC, 42 A (single output)
• Rated power: 1000 W
• Input voltage: 90–264 VAC
• Protection: MOOP (medical application compliance)
• Features: remote ON/OFF, DC OK signal
• Dimensions: 105 mm (W) × 218 mm (D) × 63.5 mm (H)
• Compliance: RoHS

How to use

Install the enclosed power supply according to the manufacturer’s mounting and ventilation instructions. Connect the AC input to a suitable 90–264 VAC mains source, observing correct wiring and grounding practices. Connect the 24 VDC output to the load, ensuring the load current does not exceed 42 A. Use the remote ON/OFF terminals to control output state and monitor the DC OK signal for system status. Verify correct operation and protections before placing the device into continuous service.

Recommendations

For reliable long-term operation, maintain adequate airflow around the unit, avoid exposure to excessive dust and moisture, and observe the specified input voltage range. Use appropriate fusing on the input and output if required by local regulations or the application, and follow medical equipment installation standards when used in patient-connected systems.
