Fonte de alimentação MEAN WELL SPU01M-05 1W 5V entrada 10,8-13,2V

The MEAN WELL SPU01M-05 is a compact PCB-mount DC-DC converter designed for applications requiring a regulated 5 V output from a 10.8–13.2 V DC input. Housed in a SIP through-hole package, this adapter delivers up to 0.2 A (1 W) of output power and meets RoHS environmental standards, making it suitable for low-power electronic circuits where board-level mounting and stable voltage are required.

Advantages

This power adapter offers a small footprint for PCB mounting, a fixed and regulated 5 V single output, and compatibility with input voltages in the 10.8–13.2 V range. Its through-hole SIP package simplifies installation in through-hole assemblies, and the unit is RoHS-compliant for reduced hazardous substances.

Suitable for

• Low-power embedded electronics
• PCB-mounted sensor modules
• Battery-powered systems operating around 12 V
• Prototyping and small electronic projects

Key specifications

• Manufacturer: mean well
• Model / MPN: SPU01M-05
• Input voltage: 10.8–13.2 V DC
• Output voltage: 5 V DC
• Output current / power: 0.2 A / 1 W
• Package: SIP through-hole (PCB mount)
• Compliance: RoHS
• EAN: 4021087040808

How to use

Mount the SPU01M-05 in the designated through-hole footprint on the PCB ensuring correct pin alignment and soldering. Apply a DC input within 10.8–13.2 V to the input pins and verify the output pins provide a stable 5 V at up to 0.2 A. Observe standard PCB handling and soldering practices and allow appropriate cooling and clearance around the converter during operation.

Recommendations

Use the converter within specified input and output limits; avoid exceeding the 0.2 A output current. Provide adequate PCB copper area for heat dissipation, ensure correct polarity on input connections, and follow RoHS-compliant assembly processes. For battery-powered applications, confirm the nominal system voltage stays within the 10.8–13.2 V window to maintain regulated 5 V output.
