Fonte de alimentação para calha DIN PULS MiniLine ML30.106 ±12/15V DC 2A 36W

DIN-rail switching power supply delivering dual adjustable outputs of ±12 to ±15 V DC with a total power of 36 W. The ML30.106 provides reliable, regulated power for industrial control systems, automation equipment, and instrumentation, with high efficiency up to 89.5% and a wide operating temperature range from -25°C to +70°C.

Advantages

Dual outputs allow powering bipolar circuits or separate loads. The unit accepts a universal AC input from 100 to 240 VAC or DC input from 110 to 300 VDC, making it suitable for global use. Built-in protections against overload, short-circuit, overvoltage, and overtemperature ensure safe operation in demanding environments. Screw terminals provide secure, vibration-resistant connections, and the compact plastic housing snaps onto standard DIN rails (TS35/7.5 or TS35/15).

Suitable for

• Industrial automation and process control systems
• Sensor and actuator power supplies
• Test and measurement equipment
• Building automation and HVAC controls
• Machinery requiring bipolar DC rails

Key specifications

• Output: ±12 to ±15 V DC adjustable, 1.5 A per channel, 36 W total
• Input: 100-240 VAC (auto-ranging) or 110-300 VDC
• Efficiency: up to 89.5%
• Ripple & noise: < 50 mVpp
• Hold-up time: > 20 ms at 230 VAC
• Isolation: 3 kVAC input/output
• Operating temperature: -25°C to +70°C
• Mounting: DIN rail TS35/7.5 or TS35/15
• Connection: screw terminals
• Housing: plastic

Recommendations

For reliable dual-rail power in compact industrial applications, the PULS MiniLine ML30.106 offers proven performance and robust protection. Verify your load requirements and adjust output voltages via the front-panel potentiometers before commissioning.
