Hager L5085 Dobradiça em poli(oximetileno) (POM) para caixa elétrica - preto

The Hager L5085 hinge is a high-quality polyoxymethylene (POM) hinge designed for use in electrical enclosures, distribution boards, and cabinets. Its robust construction and matte black finish make it a reliable choice for industrial applications requiring durable door and cover attachment.

Advantages

This hinge offers excellent chemical and UV resistance, ensuring long-lasting performance in demanding environments. The integrated, non-removable pin provides secure operation, while the 180° opening angle allows full access to enclosure interiors. Surface mount design with four mounting holes (25 mm spacing) simplifies installation.

Suitable for

• Electrical enclosures and distribution boards
• Industrial cabinets and control panels
• Door and cover attachment in harsh environments

Key specifications

• Material: Polyoxymethylene (POM)
• Colour: Black
• Dimensions: 40 x 40 x 10 mm (L x W x H)
• Mounting: Surface mount, screw-on
• Mounting holes: 4 (2 per leaf), 25 mm spacing
• Opening angle: Up to 180°
• Operating temperature: -20°C to +80°C
• Standards: RoHS, REACH
• Packaging quantity: 1 piece

Recommendations

For optimal performance, use with compatible Hager enclosures and stainless steel screws (not included). Ensure mounting surface is clean and flat before installation.
