LANVIEW RWM-IP65-GLANDS-BOTTOM caixa de parede com prensa-cabos em baixo para disjuntor ABB S200-S, 1 módulo, montagem à superfície, cinzento claro

This LANVIEW wall-box enclosure provides a secure and insulated housing for a single ABB S200-S miniature circuit breaker. Its gland bottom entry allows for neat cable management, while the transparent door offers clear visibility of the installed device. The enclosure is surface-mounted and constructed from halogen-free thermoplastic, ensuring safety and durability in various installations.

Advantages

The enclosure combines robust protection with user-friendly features. Its halogen-free material reduces toxic emissions in case of fire, and the IK07 impact rating ensures resistance to mechanical stress. The transparent door allows for quick visual inspection without opening the enclosure, enhancing maintenance efficiency.

Suitable for

• Residential and commercial electrical distribution boards
• Protection of ABB S200-S series MCBs in surface-mounted installations
• Applications requiring IP40 protection and transparent inspection windows

Key specifications

• Compatibility: ABB S200-S miniature circuit breakers
• Number of modules: 1
• Mounting type: Surface mounted
• Material: Halogen-free thermoplastic
• Colour: Light grey (RAL 7035)
• Door type: Transparent
• Cable entry: Gland bottom
• IP rating: IP40
• IK rating: IK07
• Rated insulation voltage: 500 V
• Rated impulse withstand voltage: 4 kV
• Operating temperature: -25 to +60 °C
• Glow wire test: 650 °C
• Standards: IEC/EN 60670-24, IEC/EN 62208
• DIN rail: Included

Recommendations

Ideal for electricians and panel builders seeking a reliable, halogen-free enclosure for single-module ABB MCBs. The gland bottom entry simplifies cable routing, and the transparent door allows for quick status checks. Ensure proper surface preparation for secure mounting.
