Módulo de botão de chamada Ritto 1723070

The Ritto 1723070 call button module is a surface-mounted accessory designed to integrate with compatible intercom systems. With a slim white housing and compact footprint of 90 mm width, 23 mm depth and 152 mm height, the module provides a tactile call button interface for visitor communication and internal paging. The unit is intended for visible mounting on walls or panels where a simple, durable actuation point is required.

Advantages

The module's slim profile and neutral white finish allow it to be installed in a variety of interior and exterior vestibule environments without protruding excessively. Its surface-mounted design simplifies installation when recessed mounting is not possible. The build emphasizes durability for frequent use and reliable button actuation, while the clearly defined dimensions assist in planning installation locations and cable routing.

Suitable for

Key specifications

How to use

Mount the module on a flat wall or panel surface at a convenient height for users. Connect the module to the compatible intercom wiring following the system manufacturer's wiring diagrams and safety guidelines. After secure electrical connections and mechanical fastening, verify button actuation and signal transmission by performing a functional test from both the caller and receiver ends of the intercom system. Ensure any protective covers are installed and that cable entries are sealed against moisture if installed in exposed locations.

Recommendations

For reliable long-term operation, avoid exposing the module to direct water jets and clean the housing with a soft, dry or slightly damp cloth. Use compatible Ritto intercom system components and follow local electrical codes during installation. If the environment is subject to heavy soiling or vandalism, consider supplementary protection such as a weather hood or recessed mounting alternative where possible.
