Ubiquiti UniFi Access Fail-Safe Abre-portas Elétrico (UACC-LOCK-STRIKE-SAFE-15)

Securing an access point often means choosing between security and convenience during power outages. The Ubiquiti UniFi Access Fail-Safe Electric Door Strike solves this by automatically unlocking when power is lost, ensuring safe egress while maintaining controlled access under normal conditions.

Who is it for

This electric strike is designed for integrators and facility managers deploying Ubiquiti UniFi Access systems in commercial or residential buildings. It suits doors where fail-safe operation is required by code or safety policy, such as emergency exits, stairwells, or main entrances.

Main features

• Fail-safe operation: unlocks on power loss for safe exit
• Compatible with Ubiquiti UniFi Access Hub (UA-Hub)
• Holding force of 450 kg (1000 lbs)
• Durable stainless steel faceplate
• Non-handed, reversible design for left or right swing doors
• Adjustable keeper with 1.5 mm adjustment range
• Mortise mount for flush installation
• Rated for 500,000 cycles

Specifications

• Product type: Electric door strike
• Operation mode: Fail-safe
• Input voltage: 12V DC
• Max current draw: 200 mA
• Holding force: 450 kg (1000 lbs)
• Durability: 500,000 cycles
• Mounting type: Mortise (flush mount)
• Handing: Non-handed (reversible)
• Adjustable keeper: Yes (1.5 mm adjustment)
• Faceplate material: Stainless steel
• Operating temperature: -10 to 45° C (14 to 113° F)
• Operating humidity: 0 to 95% non-condensing
• Faceplate dimensions (L x W): 124 x 43 mm (4.9 x 1.7 in)
• Body dimensions (L x W x H): 105 x 35 x 35 mm (4.1 x 1.4 x 1.4 in)
• Certifications: CE, FCC, IC
• Installation requirement: Requires UniFi Access Hub (UA-Hub)
• Connectivity: Wired (2-wire connection)

Tips

Pair this strike with the Ubiquiti UniFi Access Hub for centralized control and monitoring. Ensure your door frame is compatible with mortise mounting, and verify local fire and building codes regarding fail-safe locking hardware before installation.
