Caixa universal Bopla BA 281709 7035 299 x 173 x 90 mm alumínio cinzento-claro RAL 7035 00116335

The Bopla BA 281709 stands out with its robust die-cast aluminium construction and a precise light grey RAL 7035 powder-coated finish, offering reliable protection for industrial electronics. Its generous internal dimensions and IP66 sealing make it a dependable choice for demanding junction box and control system applications.

Highlights

• Durable aluminium body with powder-coated light grey finish (RAL 7035)
• Protection class IP66 against dust and water jets
• External dimensions: 299 x 173 x 90 mm
• Stainless steel lid screws and neoprene gasket for secure sealing
• Internal mounting bosses for PCBs or mounting plates

In daily use

This enclosure simplifies installation with pre-formed mounting bosses and a wall-mountable design. The neoprene gasket maintains a tight seal over a wide temperature range from -40 to +100 °C, ensuring long-term reliability in harsh environments.

Full specifications

• Brand: Bopla
• Model: BA 281709
• MPN: 00116335
• EAN: 4049505307098
• Enclosure Type: Universal Enclosure
• Material: Aluminium
• Colour: Light Grey (RAL 7035)
• External Length: 299 mm
• External Width: 173 mm
• External Height: 90 mm
• Protection Class: IP66
• Lid Fastening: Stainless Steel Screws
• Gasket Material: Neoprene
• Temperature Range: -40 to +100 °C
• Surface Treatment: Powder-coated
• Mounting Type: Wall Mountable
• Internal Mounting Options: Mounting bosses for PCBs/mounting plates
• Series: Bopla BA Series
• Application Area: Industrial, Electrical, Electronic, Junction Box, Control Systems

Final note

A versatile and rugged enclosure, the Bopla BA 281709 is ready to house your critical electronics with confidence.
