Conjunto de cabos de teste universais HT Instruments G3, CAT IV 600V / CAT III 1000V, 10A, cabos de medição de silicone de 1,5m com pontas de prova e pinças crocodilo, vermelho/preto 1006210

Accurate electrical measurements demand reliable connections, but standard test leads often fail in demanding environments. The HT Instruments Universalkit G3 Messleitungs-Set solves this with a complete set of double-insulated silicone leads, probes, and crocodile clips built for safety and durability. Rated CAT IV 600V and CAT III 1000V, this kit is suitable for multimeters, clamp meters, insulation testers, and other electrical testers.

Who is it for

Electricians, maintenance technicians, and field service engineers who need a dependable test lead set for a wide range of measurement tasks, from low-voltage electronics to high-energy industrial circuits.

Main features

• Complete universal set: 2 test leads (red/black), 2 test probes (red/black), and 2 crocodile clips (red/black).
• High safety rating: CAT IV 600V / CAT III 1000V for safe use on building installations and industrial equipment.
• Flexible silicone leads: 1.5 m length, double insulated, withstand temperatures from -15°C to +70°C.
• Secure connections: 4 mm safety banana plugs (straight on instrument side, angled on probe/clip side) ensure reliable contact.
• Durable probe tips: nickel-plated brass, 4 mm diameter, designed for precise probing.
• Compliant with EN 61010-031 for safety requirements of test leads.

Specifications

• Set type: Universal test lead set
• Safety rating: CAT IV 600V / CAT III 1000V
• Maximum voltage: 1000V
• Maximum current (leads): 10A
• Maximum current (crocodile clips): 1A
• Lead length: 1.5 m
• Lead material: Silicone
• Connector type (instrument side): 4mm safety banana plug (straight)
• Connector type (probe/clip side): 4mm safety banana plug (angled)
• Probe tip diameter: 4mm
• Insulation type: Double insulated
• Standard compliance: EN 61010-031
• Operating temperature range: -15°C to +70°C
• Probe tip material: Nickel-plated brass

Tips

Always verify that the test leads are rated for the voltage and category of the circuit you are measuring. Replace leads immediately if the insulation is damaged or the connectors are loose. For best longevity, avoid sharp bends near the connectors and store the set in a dry place.
