Driver LED MEAN WELL ELG-200-24DA-3Y 200W IP20 100-305V 24V

LED driver MEAN WELL ELG-200-24DA-3Y delivers regulated 24V DC output at up to 8.4A and 200W total output power. Designed for AC mains from 100 to 305V, this single-output LED driver provides combined constant voltage and constant current (CV+CC) operation with active PFC and three-wire input. The unit supports DALI dimming control and has a cable output; enclosure rating is IP20.

Advantages

The ELG-200-24DA-3Y offers stable 24V output with 200W capacity and CV+CC functionality for a variety of LED loads. Built-in power factor correction improves mains behavior, while the three-wire input and DALI dimming compatibility allow straightforward integration into lighting control systems. Its compact dimensions (71mm × 244mm × 37.5mm) make it suitable for installations where space is limited.

Suitable for

• Commercial and architectural LED lighting requiring 24V DC supply
• DALI-controlled lighting systems and networks
• Indoor LED fixtures, strips, and modules within 200W total load

Key specifications

• Brand: mean well
• Model: ELG-200-24DA-3Y
• Output: 24V DC, 8.4A, 200W
• Input voltage: 100–305V AC
• Dimming: DALI control
• Topology: CV + CC with PFC
• Protection rating: IP20
• Dimensions (W×D×H): 71 × 244 × 37.5 mm

How to use

Mount the ELG-200-24DA-3Y in a dry, ventilated indoor location with sufficient clearance for heat dissipation. Connect the AC supply to the three-wire input following local electrical codes, then connect the 24V DC output to the LED load, ensuring total load does not exceed 200W. Integrate the DALI control lines to the building DALI network for dimming functions. Verify correct polarity and secure cable connections before powering on.

Recommendations

Use this LED driver for indoor applications where IP20 protection is acceptable. Avoid exposure to moisture or dust beyond IP20 limits. For reliable long-term performance, keep the ambient temperature within the manufacturer's specified range and observe load limits; consult the full MEAN WELL datasheet for thermal and protection details.
