Fonte de alimentação AC/DC MEAN WELL DPBW06G-15, entrada 18–75 V, saída 15 V, 6 W

MEAN WELL DPBW06G-15 is a compact DC-DC converter designed for PCB mounting in a SIP through-hole package. It accepts a wide input voltage range of 18–75 Vdc and provides a regulated dual output of ±15 Vdc at up to 0.2 A per rail, delivering 6 W total power. The module is intended for low-power electronic devices and embedded systems where a stable bipolar supply is required and board-level installation saves space.

Advantages

The DPBW06G-15 offers a small footprint and through-hole SIP packaging suitable for durable PCB mounting, wide input range compatibility for industrial and vehicle power sources, and a regulated dual-output that simplifies designs requiring both positive and negative rails. It is RoHS compliant and designed for reliable operation in applications with constrained space and modest power needs.

Suitable for

• Embedded systems requiring bipolar supplies
• Industrial control boards with wide input voltage sources
• Vehicle electronics and mobile power systems
• Signal processing circuits and analog front-ends
• PCB-level power conversion in compact devices

Key specifications

• Input voltage range: 18–75 Vdc
• Output voltages: ±15 Vdc
• Output current: up to 0.2 A per rail
• Total output power: 6 W
• Package type: SIP through-hole (PCB mount)
• Converter type: DC-DC, dual output (bipolar)
• Compliance: RoHS

How to use

Mount the DPBW06G-15 onto the PCB using the provided SIP through-hole pins, ensuring correct polarity and secure solder joints. Connect the input to a DC source within the 18–75 V range and route positive and negative output rails to the target circuitry requiring ±15 V. Observe recommended board layout practices for DC-DC converters, including adequate grounding and placement of input/output decoupling components to minimize noise. Verify output voltages under load before finalizing system integration.
