Fonte de alimentação/conversor MEAN WELL SCW20B-12 20 W, entrada 18–36 V, saída 12 V

MEAN WELL SCW20B-12 is a compact DC–DC converter providing a regulated 12 V output from a wide 18–36 V DC input. Housed in a through-hole DIP package suitable for PCB mounting, this 20 W module is intended for applications where space-efficient, board-level power conversion is required. It delivers up to 1.67 A at 12 V and is RoHS compliant, offering a reliable solution for powering control electronics and small devices in industrial and vehicle environments.

Advantages

The module combines a wide input range with a fixed, well-regulated 12 V output, simplifying power design for systems operating from varying DC sources. Its through-hole DIP form factor enables secure PCB mounting and straightforward mechanical integration. With a 20 W power rating and thermal design appropriate for board-level use, it supports continuous operation for low- to moderate-power loads while meeting RoHS environmental requirements.

Suitable for

• Vehicle electronics powered from 18–36 V onboard supplies
• Industrial control circuits and automation boards
• Embedded systems and small devices requiring a stable 12 V rail
• PCB-level power distribution in equipment and instrumentation

Key specifications

• Input voltage range: 18–36 V DC
• Output voltage: fixed 12 V DC
• Maximum output current: 1.67 A
• Output power: 20 W
• Package type: through-hole DIP for PCB mounting
• Function: DC–DC conversion (isolated/non-isolated status as per manufacturer design)
• Compliance: RoHS

How to use

Mount the converter on the PCB using the through-hole pins, ensuring correct orientation and sufficient solder joints for mechanical stability. Connect a suitable 18–36 V DC input source to the input terminals and take the regulated 12 V output from the designated output pins. Provide adequate copper area or heatsinking on the PCB if operating near the maximum power rating to help dissipate heat. Observe standard PCB layout practices for DC–DC converters: keep input and output traces short, place decoupling components close to the pins, and maintain clearance from heat-sensitive components.

Recommendations
