Fonte de alimentação MEAN WELL DDR-60G-12

The MEAN WELL DDR-60G-12 is an ultra-slim industrial DC-DC DIN-rail converter that accepts 9–36 VDC input and provides a regulated 12 VDC output at up to 5 A (60 W). It is RoHS compliant and features a compact housing (52.5 mm W × 54.5 mm D × 90 mm H), designed for space-saving installation in control cabinets and industrial automation systems.

Advantages

The DDR-60G-12 offers a high power density in a narrow DIN-rail enclosure, delivering stable 12 V output under varying input conditions. Its compact dimensions enable easy integration into racks and small enclosures. RoHS compliance ensures it meets environmental and safety restrictions. The device is suitable for installations requiring reliable, continuous power for control modules and peripheral equipment.

Suitable for

• Industrial control cabinets and DIN-rail installations
• Automation equipment and PLC peripherals
• Communication devices and embedded systems requiring 12 VDC
• Bulk deployment where multiple units are installed (pack of 60 available)

Key specifications

• Model: MEAN WELL DDR-60G-12 (MPN: DDR-60G-12)
• Input voltage: 9–36 VDC
• Output voltage: 12 VDC
• Output current: 5 A
• Output power: 60 W
• Compliance: RoHS
• Dimensions (W × D × H): 52.5 mm × 54.5 mm × 90 mm
• Packaging: 60 units per pack

How to use

Mount the converter on a standard DIN rail inside a suitably ventilated enclosure. Connect the DC input (9–36 VDC) to the designated input terminals, observing correct polarity. Connect the 12 VDC output to your load, ensuring the combined load does not exceed 5 A. Verify wiring and tighten terminal screws to the manufacturer's recommended torque. Follow any additional installation notes from MEAN WELL regarding grounding and heat dissipation.

Recommendations

Use within the specified input range (9–36 VDC) and avoid exceeding the 5 A output current. Allow sufficient airflow around the unit to prevent overheating, and install in a location protected from excessive vibration, moisture, and conductive dust. For bulk installations, plan wiring and ventilation to maintain reliable operation across all units.
