Fonte de alimentação MEAN WELL DDR-60L-12 60W entrada 18-75V saída 12V

The MEAN WELL DDR-60L-12 is an ultra-slim industrial DC-DC DIN-rail converter designed to deliver a regulated 12 VDC output from a wide input range of 18–75 VDC. With a maximum output power of 60 W and a compact housing (52.5 mm x 54.5 mm x 90 mm), it is intended for space-constrained control cabinets and industrial automation installations where a reliable low-voltage supply is required. The unit is RoHS compliant.

Advantages

The converter provides a stable 12 V output at up to 5 A with efficient DC-DC conversion across a broad input voltage window. Its ultra-slim DIN-rail form factor enables straightforward mounting in tight spaces. The device’s compact dimensions and industrial design support integration into automation, control and communication systems while meeting environmental RoHS requirements.

Suitable for

• Industrial control cabinets and PLC systems
• Automation equipment and machine control
• Communication modules and low-voltage sensors
• Battery systems and vehicles with high input voltage variation

Key specifications

• Input voltage range: 18–75 VDC
• Output voltage: 12 VDC
• Maximum output current: 5 A
• Maximum output power: 60 W
• Mounting: DIN-rail
• Dimensions: 52.5 mm x 54.5 mm x 90 mm
• Protection/standards: RoHS compliant

How to use

Mount the DDR-60L-12 on a standard DIN rail inside the control cabinet and connect the input terminals to the DC supply within the specified 18–75 V range. Connect the 12 VDC output to the load, observing correct polarity. Ensure proper ventilation and follow site grounding and wiring practices. Verify output voltage under load and confirm that the connected devices do not exceed the 5 A / 60 W limit.

Recommendations

For reliable operation, avoid operating the converter continuously at its maximum rated current; allow margin for inrush currents and temperature rise. Install the unit in an environment within the manufacturer’s recommended temperature range and provide adequate clearance on the DIN rail for airflow.
