Fonte de alimentação MEAN WELL GEM60I12-P1J 60W 12V entrada 80-264V

The MEAN WELL GEM60I12-P1J is an ultra-slim AC-DC wall-mount medical adapter that delivers 12 V DC at up to 4.5 A (60 W). It accepts a wide input range of 80–264 V AC and meets RoHS requirements. The adapter provides 2×MOPP isolation suitable for medical applications. Interchangeable AC mains plugs are not included and must be ordered separately. Physical dimensions are approximately 39.1 mm (W) × 75.5 mm (D) × 56.2 mm (H).

Advantages

The adapter combines a compact, wall-mount design with a full 60 W output and wide input voltage range, enabling use in different regions when paired with the appropriate interchangeable mains plug. With 2×MOPP isolation it is designed to meet safety requirements for medical equipment. Its slim profile saves space and simplifies installation in constrained environments.

Suitable for

• Medical devices requiring 12 V DC with up to 4.5 A current
• Point-of-care equipment and bedside instruments
• Portable or space-constrained electronic equipment that mounts to a wall outlet

Key specifications

• Brand: Mean Well
• Model: GEM60I12-P1J
• Output: 12 V DC, 4.5 A (60 W)
• Input voltage: 80–264 V AC
• Safety isolation: 2×MOPP
• Dimensions (W×D×H): 39.1 × 75.5 × 56.2 mm
• RoHS compliant
• Interchangeable AC plugs: not included (sold separately)
• MPN: GEM60I12-P1J
• EAN: 4021087050180

How to use

Fit the appropriate interchangeable AC mains plug (ordered separately) for your region, then insert the adapter into the wall outlet so the DC output connector faces the device. Connect the 12 V DC output to the equipment using a compatible DC plug or cable rated for at least 4.5 A. Verify polarity and secure connections before powering the device. Ensure the connected equipment and cable ratings match the adapter’s output specifications.

Recommendations

Use the adapter in dry, ventilated locations and avoid covering the unit while in operation. Do not exceed the rated 4.5 A output. For medical installations, follow applicable standards and local regulations and use appropriate certified interchangeable mains plugs and cables.
