Fonte de alimentação MEAN WELL MFM-10-5 10W entrada 80-264V saída 5V

The MEAN WELL MFM-10-5 is an AC-DC single-output open-frame medical power supply designed for PCB mounting. It accepts a wide input voltage range of 80–264V AC and provides a regulated 5V DC output at up to 2A (10W total). The unit features 2xMOPP isolation suitable for medical applications, RoHS compliance and a compact, lightweight construction for integration into equipment where space and safety are important.

Advantages

The MFM-10-5 offers stable 5V output at up to 2A with efficient conversion across a wide input range, low weight (approximately 18 g) and a compact open-frame form factor for PCB installation. Its 2xMOPP isolation level and compliance with RoHS make it suitable for medical-grade designs that require enhanced patient safety and reduced hazardous substances.

Suitable for

• Medical instrumentation and devices requiring reinforced isolation
• Embedded systems and PCB-mounted power solutions
• Low-power electronic equipment and industrial control modules

Key specifications

• Model: MEAN WELL MFM-10-5 (MPN: MFM-10-5)
• Input voltage: 80–264V AC
• Output: 5V DC, 2A (10W)
• Output type: Single output, open-frame, PCB mount
• Isolation: 2xMOPP (medical applications)
• Compliance: RoHS
• Weight: ~18 g
• EAN: 4021087042840

How to use

Mount the MFM-10-5 on the target PCB according to the manufacturer’s recommended footprint and soldering guidelines. Ensure correct AC input wiring with appropriate fusing and that the output connections match the device requiring 5V DC. Maintain clearance and creepage distances on the PCB consistent with the 2xMOPP isolation rating and follow applicable medical safety standards during system integration and testing.

Recommendations

Use appropriate input overcurrent protection and input filtering where required, verify thermal conditions during operation, and perform EMC testing as part of final equipment certification. For medical equipment, follow relevant standards and validate the isolation and safety in the final assembled product.
