Fonte de alimentação MEAN WELL MPM-10-5, 10 W, saída 5 V, entrada 80–264 V

MEAN WELL MPM-10-5 is a compact 10 W AC-DC power adapter that provides a fixed 5 V DC output suitable for low-power electronics and embedded systems. It accepts a wide universal input range from 80 to 264 V AC and delivers up to 2 A at 5 V, with an encapsulated design optimized for PCB through-hole mounting. The module is intended for applications that require a reliable, space-saving 5 V supply and includes reinforced isolation (2xMOPP) for enhanced safety in sensitive equipment.

Advantages

The adapter offers a small footprint with a depth of 45.7 mm and a lightweight construction of 36 g, enabling use in compact assemblies and space-constrained designs. Its universal AC input simplifies system design by allowing operation across common mains voltages without additional components. Encapsulated construction and compliance with RoHS make it suitable for environments where reduced environmental impact and reliable insulation are important. The single fixed 5 V output delivers a stable regulated supply for peripheral electronics.

Suitable for

• Embedded systems and single-board computers requiring a 5 V supply
• Industrial and commercial control electronics with low power demands
• Medical and instrumentation equipment needing reinforced isolation and compact power modules
• PCB-mounted power solutions in custom electronics and prototype designs

Key specifications

• Output voltage: 5 V DC
• Maximum output power: 10 W
• Maximum output current: 2 A
• Input voltage range: 80–264 V AC
• Mounting style: PCB through-hole
• Isolation: reinforced isolation (2xMOPP)
• Construction: encapsulated module
• Depth: 45.7 mm
• Weight: 36 g
• RoHS compliant

How to use

Install the module on the PCB using the specified through-hole pads and secure solder joints for reliable electrical and mechanical connection. Observe correct input and output polarity and ensure the input is connected to an AC source within the 80–264 V range. Provide adequate clearance around the module for heat dissipation and follow applicable mounting and creepage/clearance guidelines for reinforced isolation. Verify the load does not exceed the 2 A output current rating and test the assembled system under expected operating conditions.
