Fonte de alimentação MEAN WELL SBTN01M-12 1W entrada 10,8–13,2V saída 12V

The MEAN WELL SBTN01M-12 is a compact PCB-mount DC-DC converter designed to accept an input voltage between 10.8 and 13.2 Vdc and provide a regulated 12 Vdc output at up to 0.08 A (1 W). The module is supplied in an SMD package and meets RoHS requirements, making it suitable for integration into low-power electronic assemblies where a small, reliable 12 V supply is required.

Advantages

This SBTN01M-12 adapter offers a small footprint for PCB mounting, stable 12 V output within the specified input range, and low power consumption suitable for 1 W applications. Its SMD package allows automated assembly, and RoHS compliance ensures reduced hazardous substances in manufacturing and disposal.

Suitable for

• Low-power embedded electronics
• Sensor modules and small instrumentation
• PCB designs requiring a compact 12 V rail
• Battery-operated systems with input around 12 V

Key specifications

• Manufacturer: MEAN WELL
• Model (MPN): SBTN01M-12
• Input voltage: 10.8–13.2 Vdc
• Output voltage: 12 Vdc
• Output current: 0.008–0.08 A (up to 1 W)
• Package: SMD (PCB mount)
• Compliance: RoHS
• EAN: 4021087041959

How to use

Mount the SBTN01M-12 onto the PCB following the manufacturer’s recommended land pattern and soldering profile for SMD components. Connect the input to a stable 10.8–13.2 Vdc source and take the regulated 12 Vdc output from the designated output pads. Observe correct polarity and ensure the board layout provides adequate thermal dissipation for continuous 1 W operation.

Recommendations

Use within the specified input range and do not exceed the maximum output current. For reliable operation, provide decoupling capacitors near the input and output as recommended in MEAN WELL documentation and avoid exposing the module to temperatures or mechanical stresses beyond its rated limits.
