Fonte de alimentação MEAN WELL SCWN06A-12, 12 V, 0,5 A, 6 W

MEAN WELL SCWN06A-12 is a compact DC-DC regulated single output converter delivering 12 V DC at up to 0.5 A (6 W) from a 9–18 V DC input. This through-hole DIP package is designed for embedded systems, low-power electronics and industrial control applications where a small, isolated and reliable 12 V rail is required. The module provides regulated output voltage, 3000 VDC input-to-output isolation and meets RoHS sustainability requirements. It is supplied in bulk packs for manufacturing and system integration.

Advantages

The SCWN06A-12 offers galvanic isolation up to 3000 VDC which enhances safety and noise immunity between input and output. Its regulated output ensures stable 12 V supply under varying input conditions within the specified 9–18 V range. The DIP through-hole package simplifies board-level mounting for automated or manual assembly. The converter’s small footprint and 6 W power rating make it suitable for space-constrained designs and low-power applications.

Suitable for

• Embedded systems and microcontroller power supply
• Industrial control modules and sensors
• Telecommunications and networking equipment requiring isolated rails
• Prototyping and small-series manufacturing

Key specifications

• Input voltage range: 9–18 V DC
• Output voltage: 12 V DC
• Maximum output current: 0.5 A
• Maximum output power: 6 W
• Isolation voltage (input to output): 3000 VDC
• Package type: DIP through-hole
• Output regulation: DC regulated single output
• Compliance: RoHS

How to use

Install the SCWN06A-12 into the PCB using standard through-hole soldering practices, ensuring correct pin orientation. Connect a suitable 9–18 V DC source to the input pins and draw load current from the 12 V output pins up to the 0.5 A limit. Observe basic isolation and creepage distance requirements when routing high-voltage or noisy signals near the module. Allow for adequate ventilation or thermal design in enclosed assemblies to maintain reliable operation.

Recommendations

For stable operation, keep output current within the rated 0.5 A and avoid sustained operation at maximum limits without considering ambient temperature and airflow. Use appropriate input filtering and transient suppression on the supply line if the converter will be exposed to noisy or inductive loads. Follow PCB layout guidelines for isolated converters to preserve creepage distances and to minimize EMI.
