Meanwell NDR-120-12 fonte de alimentação para calha DIN 12V 10A 120W

The Meanwell NDR-120-12 is a high-performance DIN rail power supply delivering 12V DC at 10A (120W). Designed for industrial control cabinets, it offers reliable, regulated power with comprehensive protection features. The metal housing ensures durability and efficient heat dissipation, while the LED indicator provides clear operational status.

Advantages

Compact design saves space on TS-35 DIN rails. High efficiency (88%) reduces energy loss and heat generation. Built-in protections (short circuit, overload, over voltage, over temperature) safeguard connected equipment. Wide input voltage range (90-264 VAC / 127-370 VDC) ensures global compatibility.

Suitable for

• Industrial automation systems
• PLC and control panels
• Security and access control systems
• LED lighting and signage
• Telecommunication equipment

Key specifications

• Output: 12 VDC, 10 A, 120 W
• Input: 90-264 VAC or 127-370 VDC
• Efficiency: 88%
• Ripple & Noise: 120 mVp-p
• Adjustable output voltage: 10.8-13.8 V
• Isolation: 3 kVAC I/P-O/P
• Operating temperature: -20 to +70 °C
• Cooling: Free air convection
• Protections: Short circuit, overload, over voltage, over temperature
• Certifications: UL 508, TUV EN60950-1, CE
• Mounting: DIN Rail TS-35/7.5 or TS-35/15
• Dimensions: 125.2 x 125.2 x 113.5 mm (WxHxD)
• Weight: 0.66 kg

Recommendations

For optimal performance, ensure adequate ventilation and do not exceed the rated output. Use appropriate wire gauge for connections. This power supply is ideal for demanding industrial environments where reliability is critical.
