TRIAX TMS/CKR 5x24S Multiswitch individual 4SAT+1Terr entrada 24 saída com fonte de alimentação 318605

In large residential buildings or hotels where dozens of receivers need stable satellite and terrestrial TV signals, the TRIAX TMS/CKR 5x24S multiswitch delivers reliable distribution from a single compact unit. It combines four satellite polarisations and one terrestrial feed, then routes them to up to 24 subscriber lines without signal degradation. The integrated power supply simplifies installation, and the rugged metal housing mounts easily on a wall in a technical room or basement.

Key specifications

• 4 satellite inputs (H/L, V/L, H/H, V/H) and 1 terrestrial input
• 24 subscriber outputs for individual TV connections
• Satellite frequency range: 950–2150 MHz
• Terrestrial frequency range: 47–862 MHz with 5 dB gain
• Return path support: 5–65 MHz for interactive services
• DiSEqC 2.0 switching protocol, backward compatible
• LNB power supply: 13V/18V, 0/22kHz, max 500 mA per input
• Integrated AC power supply: 230V, 50/60 Hz, 15 W consumption
• Wall-mountable metal housing

Why choose it

The TMS/CKR 5x24S stands out for its high isolation between satellite and terrestrial paths (>30 dB), preventing interference and ensuring clean signals on every output. Its low insertion loss on satellite lines and active terrestrial gain maintain signal quality over long cable runs. The built-in power supply eliminates the need for external adapters, saving space and reducing installation time. With support for the return path, it is ready for modern interactive TV and cable modem services.

Ideal use cases

• Multi-dwelling units (MDUs) distributing satellite and terrestrial TV to many apartments
• Hotels, hospitals, and office buildings requiring centralized TV distribution
• Upgrading existing single-cable systems to support more receivers
• Installations where a compact, all-in-one multiswitch with power supply is preferred

Good to know

The multiswitch is designed for indoor use and should be mounted in a dry, ventilated area. It supports standard Quattro LNBs for satellite inputs and a terrestrial antenna or cable feed. The maximum output levels comply with EN 50083-3, ensuring compatibility with a wide range of receivers. For larger installations, multiple units can be cascaded using the terrestrial trunk line.
