Eaton CI-K Caixa vazia para montagem em calha DIN, 100 x 160 x 145 mm, cinzento claro (RAL 7035), tampa preta (RAL 9005) 206883

The Eaton CI-K empty enclosure stands out with its dual-tone design: a light grey body (RAL 7035) paired with a black lid (RAL 9005), offering both functional distinction and a modern appearance. Unlike many generic enclosures, this model is specifically engineered for DIN rail mounting, allowing quick and secure installation of standard rail-mounted components directly inside the housing.

Highlights

• Compact footprint: 100 mm width, 160 mm height, 145 mm depth
• Robust polycarbonate construction for durability and impact resistance
• Designed for DIN rail mounting, simplifying component integration
• Opaque lid with plastic screws for secure closure
• Halogen-free and UV-resistant for long-term outdoor suitability

In daily use

The enclosure provides a practical solution for housing electrical and electronic components in industrial environments. Its polycarbonate material offers good impact resistance and protection against environmental factors. The internal provisions for DIN rail allow for straightforward installation of modular devices, while the screw-on lid ensures the contents remain protected yet accessible when needed.

Full specifications

• Enclosure Type: Empty Enclosure
• Mounting Method: DIN Rail Mounting
• Material: Polycarbonate
• Colour: Light Grey (RAL 7035), Lid: Black (RAL 9005)
• External Dimensions (W x H x D): 100 mm x 160 mm x 145 mm
• Ingress Protection (IP) Rating: IP65
• Impact Resistance (IK) Rating: IK07
• Lid Type: Opaque
• Lid Fasteners: Plastic Screws
• Operating Temperature Range: -40°C to +80°C
• Flammability Rating: UL 94 V-2
• Halogen-Free: Yes
• UV Resistance: Yes
• Internal Mounting Options: Provisions for DIN rail
• Series: CI-K

Final note

With its precise DIN rail integration and durable polycarbonate body, the Eaton CI-K enclosure is a reliable choice for organizing and safeguarding your rail-mounted components.
