ELEKTRA-PLUS KASETA ELEKTRA R2 quadro de distribuição embutido 18 módulos 3 filas IP40 branco porta de vidro fumado

The ELEKTRA-PLUS KASETA ELEKTRA R2 is a high-quality flush-mounted distribution board designed for residential and commercial electrical installations. With a capacity of 18 modules across 3 rows, it provides ample space for circuit breakers, RCDs, and other modular devices. The board features a transparent smoked door that allows easy visual inspection while maintaining a sleek appearance. Its robust ABS plastic body ensures durability and long service life.

Advantages

This distribution board offers easy installation with pre-punched knockouts and integrated terminal blocks for neutral and earth connections. The flush-mount design saves space and provides a clean, professional finish. The IP40 protection rating safeguards against ingress of solid objects larger than 1 mm, making it suitable for indoor use. Class II insulation ensures safety without the need for an earth connection.

Suitable for

• Residential electrical distribution
• Commercial lighting and power circuits
• Small office and retail installations
• Renovation projects requiring flush-mounted enclosures

Key specifications

• Mounting Type: Flush-mounted (Recessed)
• Module Capacity: 18 modules
• Number of Rows: 3
• IP Protection Rating: IP40
• Insulation Class: Class II
• Door Type: Transparent, Smoked
• Body Material: ABS Plastic
• Color: White (Body), Smoked (Door)
• Terminal Blocks Included: Neutral (N) and Earth (PE)
• Recess Dimensions (H x W x D): 460 x 200 x 70 mm
• Max Rated Voltage: 400V AC
• Max Rated Current: 63A
• Operating Temperature Range: -5°C to +40°C
• Glow Wire Test Temperature: 650°C
• Compliance Standards: EN 60439-3, EN 60670-24

Recommendations

For optimal performance, ensure that the recess dimensions are accurately measured before installation. Use appropriate cable glands and sealing gaskets to maintain the IP40 rating. This distribution board is compatible with standard 18 mm modular devices. Always follow local electrical codes and regulations.
