Fonte de alimentação MEAN WELL DPAN02A-12 2W 12V 0,083A RoHS

The MEAN WELL DPAN02A-12 is a compact PCB-mount DC-DC converter designed for low-power applications. It accepts an input voltage range of 9–18 VDC and provides a regulated single output of 12 VDC at 0.083 A (2 W output). The module is supplied in a SIP through-hole package suitable for board-level mounting and is RoHS compliant.

Advantages

This DC-DC converter offers a small footprint and through-hole SIP packaging for straightforward PCB installation. Its wide input range (9–18 VDC) enables use with various supply sources, and the regulated 12 V output delivers stable power for sensitive low-current circuits. RoHS compliance ensures the unit meets common environmental and safety restrictions.

Suitable for

• Low-power embedded systems and sensor modules
• Board-level power rails for control and logic circuits
• Industrial and instrumentation electronics requiring a small regulated 12 V supply

Key specifications

• Manufacturer: MEAN WELL
• Model: DPAN02A-12
• Input voltage: 9–18 VDC
• Output: 12 VDC, 0.083 A (±12 V dual-output variant noted in brief: ±12 V at 0.083 A for dual-output models)
• Output power: 2 W
• Package: SIP through-hole (PCB mount)
• Compliance: RoHS

How to use

Mount the SIP through-hole package onto the PCB following the manufacturer’s recommended footprint and soldering guidelines. Connect an appropriate 9–18 VDC input source to the input pins observing correct polarity. Use the regulated 12 V output to power low-current circuits, ensuring the load does not exceed 0.083 A. Verify thermal conditions on the PCB and provide adequate clearance for heat dissipation under continuous load.

Recommendations

Ensure the input supply is within the specified 9–18 VDC range and that the connected load stays below the 0.083 A limit. For reliable operation, place the module away from heat-sensitive components and follow PCB layout guidelines for grounding and decoupling as recommended by MEAN WELL.
