Fonte de alimentação MEAN WELL SPAN02A-15 2 W 15 V 0,134 A

The MEAN WELL SPAN02A-15 is a DC-DC converter in a SIP through-hole package designed for PCB mounting. It accepts an input voltage range of 9–18 V DC and provides a single regulated 15 V DC output at up to 0.134 A (2 W output). The module is RoHS compliant and intended for low-power embedded and electronic applications where a compact, board-mounted isolated or non-isolated supply is required.

Advantages

The SPAN02A-15 offers a small footprint for easy PCB integration, stable 15 V output within the specified input range, and low power dissipation suitable for 2 W loads. Its SIP through-hole format simplifies mounting and replacement on prototype and production boards. RoHS compliance ensures conformity with environmental standards.

Suitable for

• Low-power embedded systems
• Sensor and control circuits
• PCB-mounted auxiliary power for industrial electronics
• Prototyping and small production runs

Key specifications

• Input voltage: 9–18 V DC
• Output: 15 V DC, 0.134 A (2 W)
• Package: SIP through-hole for PCB mount
• Compliance: RoHS
• Manufacturer: MEAN WELL, model SPAN02A-15
• EAN: 4021087041126

How to use

Mount the SPAN02A-15 in a compatible SIP footprint on the PCB and solder the pins according to the board layout. Apply an input voltage within 9–18 V DC to the designated input pins and take the regulated 15 V DC output from the output pins. Observe correct polarity and follow standard soldering and handling precautions for through-hole components. Verify connections and output voltage before connecting sensitive loads.

Recommendations

For reliable operation, keep the load at or below the rated 0.134 A and ensure adequate PCB copper area or thermal paths for heat dissipation. Avoid exceeding the input voltage range and protect the module from short circuits and moisture. Use appropriate input decoupling and fusing as needed for your system design.
