RUKO FRS-DIN8033-HM-TiAlN-Ø10,0mm fresa de topo VHM, 4 arestas, revestida a TiAlN, DIN 8033, 10mm de diâmetro de corte

Machinists and CNC operators rely on this solid carbide end mill for precise profiling, slotting, and contouring in steel, stainless steel, cast iron, and non-ferrous metals. The TiAlN coating provides high heat resistance and extended tool life, even in demanding applications up to 55 HRC.

Key specifications

• Tool type: End mill
• Material: Solid carbide (VHM)
• Coating: TiAlN (Titanium Aluminum Nitride)
• Standard: DIN 8033
• Cutting diameter (D1): 10.0 mm
• Shank diameter (D2): 10.0 mm
• Overall length (L1): 72 mm
• Cutting length (L2): 22 mm
• Number of flutes: 4
• Helix angle: 30°
• Shank type: Cylindrical
• Cutting diameter tolerance: h6
• Shank diameter tolerance: h6
• Cutting edge type: Center cutting
• Direction of cut: Right-hand cut
• Max. material hardness: Up to 55 HRC
• Series: Gühring 3000
• Manufacturing process: Precision ground

Why choose it

Precision ground from solid carbide and finished with a TiAlN coating, this end mill delivers consistent performance and wear resistance in general-purpose machining tasks.

Ideal use cases

• Milling steel and stainless steel components
• Machining cast iron parts
• Working with non-ferrous metals

Good to know

The cylindrical shank with h6 tolerance ensures secure clamping in standard collets and holders.
