WAGO 285-440 Tiras de identificação, amarelo, impressão preta, 10 marcadores por tira, 10 tiras por cartão, 100 marcadores no total, para bornes de série 285

The WAGO 285-440 is a high-quality marking strip designed for use with WAGO 285 Series terminal blocks. This unprinted marker strip features a yellow background intended for black printing, allowing for clear and durable identification of electrical connections. Each strip contains 10 markers with a 5 mm pitch, and each card includes 10 strips, providing a total of 100 markers per unit. Made from polyamide 6.6 (PA 6.6) with a UL 94 V-2 flammability rating, these markers are halogen-free, silicone-free, and RoHS/REACH compliant, ensuring safe and reliable performance in demanding environments.

Advantages

These marking strips offer a snap-on mounting method for quick and secure attachment to terminal blocks. The unprinted design allows for custom labeling using WAGO's WMB (WAGO Multi-Block) system or other compatible printers. The robust polyamide material ensures long-lasting durability and resistance to temperatures ranging from -35 to +85 °C.

Suitable for

• Industrial control panels
• Building automation systems
• Electrical distribution boards
• Machine and plant engineering

Key specifications

• Product Type: Marking Strip
• Compatibility: WAGO 285 Series Terminal Blocks
• Marker Type: WMB (WAGO Multi-Block)
• Printing Status: Unprinted
• Background Color: Yellow
• Intended Print Color: Black
• Material: Polyamide 6.6 (PA 6.6)
• Flammability Rating: UL 94 V-2
• Operating Temperature Range: -35 to +85 °C
• Storage Temperature Range: -35 to +85 °C
• Number of Markers per Strip: 10
• Number of Strips per Card: 10
• Total Markers per Unit: 100
• Marker Pitch: 5 mm
• Mounting Method: Snap-on
• Halogen-free: Yes
• Silicone-free: Yes
• RoHS Compliant: Yes
• REACH Compliant: Yes

Recommendations

For optimal results, use with WAGO 285 series terminal blocks and WAGO marking software or compatible printers. Ensure the markers are applied to clean, dry surfaces for maximum adhesion and legibility.
