Caixa universal Bopla Bocube Alu BA-S 140806 F, 159 x 86 x 60 mm, cinzento-claro RAL 7035, alumínio, IP66/IP67 00163125

Universal aluminium enclosure from the Bocube Alu series, offering robust protection for industrial and electronic components. Its die-cast aluminium body with powder coating provides excellent durability and corrosion resistance.

Advantages

High protection class IP66/IP67 and impact resistance IK08 ensure reliable operation in harsh environments. The screw-fastened lid with stainless steel screws and PUR gasket guarantees a secure seal. Operating temperature range from -40 to +80 °C allows use in extreme conditions.

Suitable for

• Industrial control systems
• Electrical installations
• Electronic component housing
• Outdoor and indoor applications

Key specifications

• External dimensions: 159 x 86 x 60 mm
• Material: Aluminium, powder-coated
• Colour: Light grey RAL 7035
• Protection class: IP66 / IP67
• Impact resistance: IK08
• Lid fastening: Screw-fastened, stainless steel screws
• Gasket material: Polyurethane (PUR)
• Operating temperature: -40 to +80 °C

Recommendations

Ideal for demanding applications where reliable sealing and mechanical strength are required.
