Fonte de alimentação MEAN WELL DPAN02B-15 2W 15V 18-36V entrada

The MEAN WELL DPAN02B-15 is a compact DC-DC converter designed for PCB mounting. It accepts an input voltage range of 18–36 V DC and delivers a single 15 V DC output with a rated power of 2 W. The module is supplied in a SIP through-hole package and is RoHS compliant, making it suitable for integration into electronic equipment that requires a small, stable power source.

Advantages

The DPAN02B-15 offers a wide input voltage span that accommodates common vehicle and industrial supply ranges, a small footprint for PCB-mounted applications, and a regulated 15 V output at up to 0.067 A. Its through-hole SIP package simplifies soldering and mechanical retention on PCBs, while RoHS compliance supports environmental and safety requirements.

Suitable for

• Embedded electronics and control boards
• Industrial instrumentation with 18–36 V supplies
• Prototyping and small-form-factor devices requiring 15 V
• Applications where a compact PCB-mounted DC-DC converter is needed

Key specifications

• Manufacturer: MEAN WELL
• Model (MPN): DPAN02B-15
• Input voltage: 18–36 V DC
• Output voltage: 15 V DC
• Output current: 0.067 A (67 mA)
• Output power: 2 W
• Package: SIP through-hole (PCB mount)
• Compliance: RoHS
• EAN: 4021087046411

How to use

Mount the DPAN02B-15 in a matching SIP through-hole footprint on the PCB and solder according to standard through-hole practices. Connect an appropriate 18–36 V DC input supply to the input pins and take the regulated 15 V DC from the output pins. Verify correct pin orientation and observe polarity when wiring. Provide adequate PCB clearance and thermal paths as required by your design to ensure reliable operation at the rated power.

Recommendations

Use short, well-routed traces for input and output connections and decoupling capacitors as recommended by your circuit design guidelines. Avoid exceeding the 2 W output rating and operate within the specified input range. For improved reliability, place the module away from high-temperature components and ensure proper solder joints and mechanical support on the PCB.
